Send InquiryLanding Valve
Price 2400.0 INR/ Number
Landing Valve Specification
- Material
- Gunmetal/bronze/body, stainless steel or aluminum fittings
- Valve Size
- 63 mm (2-1/2 inch)
- Valve Type
- Hand wheel operated, right angled pattern
- Control System
- Manual handwheel operation
- Features
- Corrosion resistant, easy operation, high durability, conforms to IS:5290 Type-A
- Connection Type
- Flanged inlet, instantaneous male outlet
- Sealing
- Rubber washer/gasket
- Application
- Firefighting water supply lines, hydrant systems, commercial and industrial buildings
- Structure
- Other
- Type
- Landing Valve
- Size
- 80mm
- Power
- M Ampere (amp)
- Pressure
- O PSI
- Media
- Water
- Port Size
- 63 mm
- Color
- Red
- Temperature
- Up to 80C Celsius (oC)
- Disc
- Brass/bronze or rubber-faced disc
- Operation
- Open/close by hand wheel
- Mounting
- Vertical (upright) on wet riser/inlet pipe
- Body Test Pressure
- 2.4 MPa (24 bar)
- Handle Material
- Cast iron or aluminum (Handwheel)
- Finish
- Natural bronze/painted/red powder coated
- Outlet Connection
- 63 mm female instantaneous to BS336/ISI
- Seat Test Pressure
- 1.7 MPa (17 bar)
- Weight
- Approx. 7-8 kg
Landing Valve Trade Information
- Minimum Order Quantity
- 50 Number
- Payment Terms
- Cash in Advance (CID)
- Supply Ability
- 100 Per Month
- Delivery Time
- 7 Days
- Main Domestic Market
- All India
About Landing Valve
VEECO Landing Valve (Fire Hydrant Valve)
By Vamsy Engineering Co.
Product Overview
VEECO Landing Valves are designed for efficient control and delivery of water in firefighting systems. Manufactured with precision and durability, they comply with Indian Standards and ensure reliable performance in emergency situations.
1. Standard Compliance
- Conforming to IS: 5290 (Type A / Type B)
- ISI Marked
-
2. Material of Construction
- Body: Gunmetal / Bronze (IS: 318 Grade LTB2)
- Bonnet: Gunmetal
- Spindle: Stainless Steel (SS 410 / SS 304)
- Hand Wheel: Cast Iron / Aluminium
- Seat: Renewable type (PTFE / Gunmetal)
- Gland Packing: Asbestos-free
3. Size & End Connections
- Inlet: 63 mm / 80 mm / 100 mm (Flanged as per IS 6392)
- Outlet: 63 mm Female Instantaneous Coupling (IS 903)
- Type: Single Head / Double Head
4. Pressure Rating
- Working Pressure: 16 kg/cm (PN16)
- Test Pressure: Up to 24 kg/cm
5. Design Features
- Oblique pattern design for smooth water flow
- Screw-down type valve mechanism
- Non-rising spindle
- Replaceable rubber washer
- Chain & cap for outlet protection
- Provision for locking arrangement
-
6. Finish
- Natural Gunmetal / Epoxy Coated Finish
- Corrosion-resistant construction
7. Operation
- Handwheel operated
- Clockwise closing mechanism
8. Applications
- Commercial Buildings
- Industrial Facilities
- Residential Complexes
- Warehouses & Fire Safety Systems
-
9. Testing
- Hydraulic pressure tested
- Leakage and seat test ensured before dispatch
